GE IC200CHS002K – VersaMax Box-Style I/O Carrier Module

In stock

Product Introduction

The IC200CHS002K, manufactured by General Electric (GE Fanuc, now Emerson Automation), is a compact, high-performance box-style I/O carrier module within the VersaMax PLC system. It serves as a dedicated mounting and wiring base for a single VersaMax I/O module, providing reliable backplane communication, secure field wiring termination, and power distribution. Designed for industrial automation environments, it streamlines I/O system assembly, maintenance, and troubleshooting by enabling hot-swap of I/O modules without disconnecting field wiring. The “K” suffix denotes a specific industrial-grade variant with enhanced durability and compatibility features.

Technical Specifications

Manufacturer: General Electric (GE Fanuc / Emerson Automation)
Model: IC200CHS002K
Series: VersaMax PLC System
Type: Box-Style Terminal I/O Carrier
Terminal Configuration: 36 IEC box-style terminals (A1–A18, B1–B18)
Supported I/O Points: Up to 32 I/O points + 4 shared power/common connections
Voltage Rating: 0–264 VAC; 300 VAC transient protection
Current Rating: 2A per I/O point; 8A per power/ground segment
Wire Compatibility: Solid/stranded copper (AWG #14–#22 single wire; AWG #18 dual wires)
Terminal Torque: 0.37–0.45 lb-ft (0.5–0.6 N·m)
Backplane Current Consumption: 805mA (typical)
Power Dissipation: 2.48W (8.8 BTU/hour)
Dimensions (W×H×D): 110.5mm × 70mm × 139.7mm
Weight: 0.50kg (1.1lbs)
Mounting: Horizontal DIN rail (7.5mm × 35mm); panel-mountable for vibration resistance
Operating Temperature: -40°C to +70°C (-40°F to 158°F)
Protection Class: IP20 (dust-protected, finger-safe)
Certifications: CE, UL, CSA (industrial safety and EMC compliance)

Key Features

Modular & Hot-Swappable Design: Supports installation and replacement of one VersaMax I/O module without rewiring field devices, minimizing system downtime.
Secure Terminal Wiring: 36 IEC box-style terminals with clear labeling accommodate standard copper wires, ensuring reliable connections and simplifying maintenance.
Keying Mechanism: Equipped with adjustable keying dials to prevent mismatched I/O module installation, safeguarding system integrity.
Transparent Protective Door: Hinged transparent cover shields terminals from dust, debris, and accidental contact while allowing visual inspection.
Tool-Free Backplane Connection: Carrier-to-carrier male/female connectors enable quick, cable-free backplane linking for seamless system expansion.
Robust Environmental Resistance: Wide temperature tolerance and IP20 rating ensure reliable operation in harsh industrial environments.
High Current Capacity: 2A per point and 8A per power segment support high-power I/O devices without overloading.
