GE IC200UEX626 – VersaMax Micro 6-Channel Analog Expansion Module (4-In/2-Out)

In stock

Product Introduction

The IC200UEX626, manufactured by General Electric (GE Fanuc, now Emerson Automation), is a compact, high-density analog expansion module in the VersaMax Micro PLC series. Designed to extend the analog I/O capability of VersaMax Micro controllers, it integrates 4 isolated analog inputs and 2 configurable analog outputs into a single, space-saving unit. It serves as a cost-effective solution for small-to-medium industrial control systems requiring precise sensor signal acquisition and analog actuator driving, ideal for applications where panel space is limited and reliable performance is critical.

Technical Specifications

Manufacturer: General Electric (GE Fanuc / Emerson Automation)
Model: IC200UEX626
Series: VersaMax Micro PLC System
Module Type: Mixed Analog Input/Output Expansion Module
Analog Inputs: 4 differential, isolated channels
Analog Outputs: 2 single-ended, configurable channels (voltage/current)
Resolution: 12-bit (for both inputs and outputs)
Input Ranges: Voltage: 0–10VDC, ±10VDC; Current: 0–20mA, 4–20mA
Output Ranges: Voltage: 0–10VDC; Current: 4–20mA (software-selectable)
Accuracy: ±0.2% of full scale (typical, 25°C)
Power Supply: 24VDC (19.2–30VDC acceptable)
Power Consumption: 3W (max)
Sensor Supply: 24VDC / 200mA (user power output)
Isolation: 250VAC continuous (channel-to-logic); 1500VAC for 1 minute
Dimensions (W×H×D): 75mm × 80mm × 47mm
Weight: 0.5kg (1.1lbs)
Operating Temperature: -20°C to +60°C (-4°F to 140°F)
Storage Temperature: -40°C to +70°C (-40°F to 158°F)
Relative Humidity: 5%–95% (non-condensing)
Protection Class: IP20 (for cabinet mounting)
Mounting: DIN rail or VersaMax Micro controller option slot
Hot-Swappable: Yes (replacement without system shutdown)

Key Features

Compact 6-Channel Design: Combines 4 inputs and 2 outputs in a single module to save cabinet space and reduce system cost.
12-Bit Precision: Delivers high-resolution analog-to-digital and digital-to-analog conversion for accurate process monitoring and control.
Isolated Input Channels: 4 differential inputs with 250VAC isolation reject common-mode noise and protect against electrical interference in harsh environments.
Configurable Outputs: 2 software-selectable voltage (0–10VDC) or current (4–20mA) outputs to drive valves, actuators, and transmitters.
Integrated Sensor Power: Provides 24VDC / 200mA auxiliary power for field sensors, eliminating the need for an external power supply.
Diagnostic LEDs: Power and status indicators for quick troubleshooting and real-time monitoring of module health.
Easy Integration: Plugs directly into VersaMax Micro controller option slots for seamless configuration via programming software.
Wide Environmental Tolerance: Operates reliably in extreme temperatures and humidity for deployment in industrial, commercial, and infrastructure applications.
