GE IC670MDL740K – 16-Channel Positive Logic Sourcing Discrete Output Module

In stock

Product Introduction: The IC670MDL740K is a high-density, high-reliability discrete output module manufactured by GE Fanuc (GE Intelligent Platforms) as part of the Genius Field Control I/O system. Designed for industrial automation, it converts digital control signals from a PLC or Bus Interface Unit (BIU) into 12/24VDC sourcing outputs to drive low-current field devices such as solenoids, relays, indicators, and small actuators. Its rugged design, electrical isolation, and built-in protection make it suitable for high-noise, harsh industrial environments, serving as a critical link between digital controllers and physical process equipment.

Technical Specifications

Manufacturer: GE Fanuc (GE Intelligent Platforms / Emerson Automation)
Model: IC670MDL740K
Series: Genius Field Control I/O System
Module Type: Discrete (Digital) Output Module
Output Channels: 16 channels, grouped into 2 banks of 8; positive logic sourcing (current flows from module to load)
Output Voltage Range: 9.2–29.5VDC (operating); 12VDC / 24VDC (nominal)
Output Current: 0.5A per channel (continuous, resistive load); max 4A total per module
Inrush Current: 2A per channel (max 100ms duration)
Output Response Time: 200µs typical (0.5A resistive load)
Output Dropout Voltage: ≤0.5V maximum
Leakage Current: ≤0.5mA at 30VDC (off-state)
Minimum Load Current: 1mA per channel
Backplane Power Consumption: 111mA @ 5VDC (from BIU)
Field Power: External 10–30VDC required for load operation
Isolation: 250VAC continuous; 1500VAC for 1 minute (channel-to-logic)
Dimensions (W×H×D): 85mm × 110mm × 60mm
Weight: 0.45kg
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Relative Humidity: 5%–95% (non-condensing)
Certifications: CE, UL 508, CSA, IEC 61010-1
Protection Class: IP20 (front panel)
Mounting: DIN rail or direct panel mount; compatible with Genius BIU (e.g., IC670GBI002)

Key Features

16-Channel High-Density Sourcing Output: Delivers positive logic (sourcing) outputs for direct connection to DC loads, simplifying wiring and reducing system complexity.
Robust Electrical Isolation: 250VAC continuous isolation between field circuits and internal logic prevents ground loops and protects the PLC backplane from voltage spikes and EMI.
Built-In Overcurrent & Short-Circuit Protection: Each channel includes electronic current limiting and short-circuit protection (100µs response) to safeguard the module and connected loads.
LED Diagnostic Indicators: Individual channel status LEDs (ON/OFF) plus module-level POWER and FAULT LEDs enable real-time monitoring and quick troubleshooting.
Wide Voltage Compatibility: Supports 9.2–29.5VDC field power, accommodating both 12VDC and 24VDC industrial standards.
High-Speed Switching: 200µs response time supports fast, frequent switching for dynamic process control applications.
