GE IC693MDL940L – Series 90-30 16-Channel Low‑Power Relay Output Module

In stock

Product Introduction:

The IC693MDL940L is a cost‑optimized, low‑power relay output module designed for the GE Fanuc Series 90-30 PLC platform. It provides 16 normally open (NO) electromechanical relay contacts to switch low‑to‑medium DC and AC loads. Engineered for standard industrial environments, it offers reliable isolation, compact integration, and economy for general‑purpose control.

Technical Specifications

Manufacturer: GE Fanuc (Emerson Automation)
Model: IC693MDL940L
Series: Series 90-30 PLC System
Module Type: Discrete Relay Output Module
Output Configuration: 16 channels, normally open (NO)
Output Groups: 4 isolated groups (4 channels per group)
Voltage Range: 5–30VDC / 5–250VAC (50/60Hz)
Rated Voltage: 24VDC, 120/240VAC
Max Current per Channel: 1A (resistive load)
Max Current per Common: 4A
Maximum Inrush Current: 5A per channel
Isolation: 1500VAC (1 min) field‑to‑logic; 500VAC between groups
Response Time: ≤15ms (ON/OFF)
Backplane Power: 7mA @ 5VDC (logic); 135mA @ 24VDC (relay)
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5–95% non‑condensing
Certifications: CE, UL 508, CSA, Class 1 Div 2 Groups A/B/C/D, T4A
Dimensions: 110mm × 80mm × 40mm
Weight: 0.4kg

Key Features

16 Low‑Power Relay Outputs: Each channel switches up to 1A resistive loads, ideal for solenoids, indicators, and small contactors.
Four‑Way Electrical Isolation: 1500VAC field‑to‑logic isolation and 500VAC inter‑group isolation prevent cross‑talk and ground loops.
Wide Compatibility: Supports both DC (5–30V) and AC (5–250V) loads for global deployment.
LED Status Indicators: 16 green individual LEDs provide real‑time visual status for each output.
Tool‑Less Wiring: Hinged terminal door and color‑coded blocks simplify installation and maintenance.
Compact & Cost‑Efficient: Reduced power draw and smaller footprint suit high‑density, budget‑conscious systems.
Rugged Industrial Design: Withstands vibration, shock, and wide temperature ranges for long‑term reliability.
