GE IC693MDR390C – Series 90-30 24‑Point Mixed Input/Output Module

In stock

Product Introduction:

The IC693MDR390C is a high‑density mixed I/O module integrating 16 discrete inputs and 8 relay outputs for the GE Series 90-30 PLC system. It combines input sensing and output control in a single compact unit, reducing rack space, wiring complexity, and system cost for small‑to‑medium automation systems. The module’s versatile design makes it ideal for applications requiring both monitoring and control capabilities in a limited footprint.

Technical Specifications

Manufacturer: GE Fanuc (Emerson Automation)
Model: IC693MDR390C
Series: Series 90-30 PLC System
Module Type: Mixed Discrete Input/Output Module
Input Points: 16 (24VDC sinking/sourcing)
Output Points: 8 (relay, normally open)
Input Voltage: 24VDC ±10%
Input Current: 10mA typical per point
Output Load: 2A @ 24VDC or 120VAC per channel
Isolation: 1500VAC (1 min) between I/O and logic
Backplane Power: 150mA @ 5VDC
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Humidity: 5–95% non‑condensing
Certifications: CE, UL 508, CSA
Dimensions: 110mm × 80mm × 40mm
Weight: 0.42kg

Key Features

16‑In/8‑Out Mixed I/O: Combines input and output functionality to save rack space and reduce system complexity.
24VDC Inputs: Compatible with standard industrial sensors (proximity, photoelectric, limit switches) for seamless integration.
Relay Outputs: Capable of switching both DC and AC loads up to 2A, supporting direct control of solenoids, contactors, and small motors.
LED Diagnostics: Individual LEDs for each input and output point enable real‑time status monitoring and quick fault detection.
Space‑Saving Design: Reduces wiring time and system footprint, ideal for compact control panels and small automation systems.
Rugged Construction: Withstands industrial environmental conditions for long‑term reliability.

Application Scenarios

Small Assembly Lines: Monitors sensors and controls actuators in compact workcells and manufacturing stations.
Material Handling: Senses limit switches and drives small motors/solenoids in conveyor systems and storage equipment.
Building Automation: Monitors door/window sensors and controls lighting/ventilation systems in commercial buildings.
HVAC Systems: Regulates dampers, valves, and fan motors based on sensor inputs in heating, ventilation, and air conditioning systems.
General Industrial Control: Provides integrated monitoring and control for small‑scale automation projects and machine control applications.
