GE IC697ACC720 – Series 90‑70 16‑Channel Digital Output Module

In stock

Product Introduction:

The IC697ACC720 is a high‑density discrete output module for the Emerson (formerly GE Fanuc) Series 90‑70 PLC platform, providing 16 optically isolated digital output points. It interfaces with standard industrial loads (solenoids, relays, LED indicators, small DC motors) and supports 24VDC/48VDC output voltages, with 0.5A maximum current per channel. Engineered for factory automation and process control systems, it offers robust noise immunity, fast response times, and advanced diagnostics for reliable operation in harsh industrial environments.

Technical Specifications

Manufacturer: Emerson Automation (formerly GE Fanuc)
Model: IC697ACC720
Series: Series 90‑70 PLC System
Module Type: Discrete Output Module
Output Points: 16 (optically isolated, individual channel isolation)
Output Voltage: 24VDC ±10% / 48VDC ±10%
Max Current per Channel: 0.5A (resistive load)
Max Current per Common: 4A (8 channels per common group)
Response Time: ≤1ms (ON/OFF)
Isolation: 1500VAC (1 min) between channel and logic; 500VAC between groups
Backplane Power: 120mA @ 5VDC
Operating Temperature: 0°C to +60°C (standard); -40°C to +70°C (extended)
Storage Temperature: -40°C to +85°C
Certifications: CE, UL, CSA, RoHS, Class 1 Div 2
Dimensions: 102mm × 152mm × 64mm
Weight: 0.5kg

Key Features

16 High‑Density Outputs: Maximizes I/O capacity in a single Series 90‑70 slot, reducing rack space and wiring complexity.
Dual Voltage Support: Compatible with 24VDC and 48VDC industrial loads, supporting global application requirements.
Optical Isolation: 1500VAC isolation protects against electrical noise, ground loops, and voltage spikes in harsh environments.
Fast Response Time: ≤1ms ON/OFF switching ensures precise control for high‑speed automation processes.
LED Status Indicators: 16 green individual LEDs provide real‑time visual status for each output point.
Overcurrent Protection: Each channel features self‑resetting overcurrent protection to prevent load damage.
Rugged Industrial Design: Withstands vibration, shock, and wide temperature ranges for reliable operation in manufacturing and process plants.
