Technical Specifications:
- Manufacturer: GE Fanuc (Emerson Automation)
- Series: Series 90-70 PLC System
- Module Type: AC/DC universal power supply (kit), single-slot
- Input Voltage: AC: 90–264VAC (47–63Hz); DC: 100–150VDC
- Outputs: +5VDC (4.90–5.25V), +12VDC (11.75–12.6V), -12VDC (-12.6–-11.75V)
- Power Rating: 100W total
- Input Power: 135W typical; 160W maximum
- Efficiency: ≥85% @ full load
- Protection: Overvoltage, overcurrent, short circuit, overheating, surge, reverse polarity
- LED Indicators: Power OK, Fault, Input Type
- Redundancy: Supports parallel redundant operation (load sharing)
- Kit Contents: Power supply module, mounting brackets, screws, user manual, wiring guide
- Backplane Compatibility: Series 90-70 universal backplane
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Weight: Approx. 1.6 kg
- Certifications: CE, UL, CSA, Class 1 Div 2, RoHS
Key Features:
- All-In-One Kit: Includes every part needed for installation.
- Identical Performance: Same electrical specs as the standard IC697PWR711.
- Dual Input & Triple Output: Universal AC/DC input and precise ±12V for analog/comm modules.
- Redundancy Support: Parallel operation for fault tolerance in critical systems.
- Comprehensive Protection: Safeguards against all common electrical faults.
- Industrial Reliability: Wide temperature tolerance and ruggedness for harsh environments.
- Easy Maintenance: Clear documentation and LED diagnostics for quick installation and troubleshooting.
Applications:
- Rapid Deployment Projects: New factories and greenfield installations needing fast setup.
- Redundancy System Spares: Direct replacement for existing redundant power supplies.
- Critical Mixed-Source Power: Plants with both mains and UPS backup needing redundancy.
- Complex Cabinet Integration: Full 10-slot racks requiring a complete, ready-to-install power solution.
