Technical Specifications:
- Manufacturer: GE Fanuc (Emerson Automation)
- Series: Series 90-70 PLC System
- Module Type: AC/DC universal power supply, single-slot
- Input Voltage: AC: 90–264VAC (47–63Hz); DC: 100–150VDC
- Outputs: +5VDC, +12VDC, -12VDC
- Power Rating: 100W total
- Efficiency: ≥85% @ full load
- Protection: Overvoltage, overcurrent, short circuit, overheating, surge, reverse polarity
- LED Indicators: Power OK, Fault, Input Type
- Redundancy: Supports parallel redundant operation (load sharing)
- Backplane Compatibility: Series 90-70 universal backplane
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Weight: Approx. 1.64 kg
- Certifications: CE, UL, CSA, Class 1 Div 2, RoHS
Key Features:
- Dual Input Compatibility: Works with AC mains or DC (battery/UPS) inputs.
- Triple Isolated Outputs: +5V (logic), ±12V (analog/communications) for mixed systems.
- High Power Output: 100W for full 10-slot racks with CPU, I/O, and comms modules.
- Redundancy Capable: Parallel operation with load sharing; fault-tolerant for critical systems.
- Full Protection Suite: Guards against all common electrical faults.
- Industrial Hardening: Wide temperature tolerance and ruggedness for harsh environments.
- Diagnostic LEDs: Indicate power status, input type, and fault origin.
Applications:
- Large PLC Systems: Full 10-slot racks with CPUs, I/O, and communication modules.
- Redundant Control Systems: Power plants, refineries, and steel mills requiring 24/7 uptime.
- Mixed AC/DC Sites: Facilities with both mains and UPS/battery backup.
- Harsh Environments: High-temperature cabinets, outdoor enclosures, and corrosive areas.
