GE TKM3F1200 - Three-Phase Terminal Kit for 1200 Amp Applications

GE TKM3F1200 – Three-Phase Terminal Kit for 1200 Amp Applications

In stock

Product Introduction:
The TKM3F1200 is a heavy-duty terminal kit designed for GE electrical distribution and power control equipment. The “TKM” designation stands for Terminal Kit Mounting, indicating it is a wiring termination accessory. The “3F” indicates it is designed for three-phase power applications. The “1200” specifies that it is rated for 1200 Amperes of continuous current. This terminal kit provides the physical connection points for large power cables (typically 500 kcmil to 750 kcmil copper or equivalent aluminum) to be terminated onto bus bars, circuit breakers, contactors, or disconnects. It is a critical component in high-power electrical switchgear, motor control centers (MCCs), and distribution panels.

Technical Specifications:
Product Type: Terminal Kit for high-power electrical equipment
Phase Configuration: Three-Phase (3F) plus ground
Current Rating: 1200 Amperes continuous at 75 degrees Celsius
Voltage Rating: 600V AC maximum
Conductor Size: Accepts copper conductors from 350 kcmil to 750 kcmil (or aluminum 500 kcmil to 1000 kcmil)
Material: High-conductivity copper alloy with tin plating
Torque Specification: 350-450 inch-pounds (depending on conductor size)
Standards: UL 486A, UL 486B, CSA C22.2 No. 45
Temperature Range: -40 to +105 degrees Celsius
Mounting: Bolt-on to bus bars or equipment lugs

Functional Features:
High Current Capacity: Safely terminates 1200 Amp cables without overheating or voltage drop.
Corrosion Resistant: Tin-plated copper resists oxidation, ensuring a reliable connection over the life of the equipment.
Easy Installation: Large bolt holes and generous clearance make wire insertion and torqueing straightforward.
Code Compliant: Meets all UL and CSA requirements for power distribution equipment.
Flexible Configuration: Can be used with copper or aluminum conductors, and in various phase configurations (3-phase, single-phase, etc.).

Application Scenarios:
Motor Control Centers (MCCs): Terminates the large feeder cables that supply power to motor starters.
Switchgear: Connects bus bars to circuit breakers and disconnect switches in low-voltage switchgear.
Generator Connections: Terminates the large cables that connect generators to the main bus.
Transformer Connections: Connects transformer secondary windings to the main distribution bus.
