GE TKMA30800WL - Terminal Kit Mounting Adapter with Weather-Lock Sealing for 30 to 800 Amp Applications

GE TKMA30800WL – Terminal Kit Mounting Adapter with Weather-Lock Sealing for 30 to 800 Amp Applications

In stock

Product Introduction:
The TKMA30800WL is a heavy-duty terminal kit mounting adapter manufactured by GE for use in electrical control and distribution equipment. The “TKMA” designation stands for Terminal Kit Mounting Adapter, indicating it serves as an interface or transition piece between different types of termination points. The “30800” indicates a current rating range of 30 to 800 Amperes. The “WL” suffix denotes the Weather-Lock feature, which is a critical upgrade providing enhanced environmental sealing. This adapter allows installers to connect conductors of varying sizes to a single termination point while protecting the connection from moisture, dust, and corrosive atmospheres. It is commonly used in outdoor switchgear, marine applications, and industrial facilities exposed to harsh weather conditions.

Technical Specifications:
Product Type: Terminal Kit Mounting Adapter with Weather-Lock Sealing
Current Rating Range: 30 Amperes to 800 Amperes continuous
Voltage Rating: 600V AC maximum (1000V AC for specific configurations)
Conductor Range: Accepts conductors from 14 AWG (15A) up to 600 kcmil copper or 750 kcmil aluminum
Material: High-conductivity copper alloy with nickel plating and silicone weather seals
Standards: UL 486, UL 486A, UL 486B, CSA C22.2 No. 45, IEEE 386
Temperature Rating: 75 degrees Celsius at 600V, 90 degrees Celsius at 300V
IP Rating: IP65 when mated with Weather-Lock housing (dust tight and water jet resistant)
Torque Specification: 350 to 500 inch-pounds depending on conductor size and material
Mounting: Bolt-on or screw-mount with gasketed flange for environmental sealing
Color Code: Color-coded by current rating for quick identification (WL suffix indicates white/gray weather-lock housing)

Functional Features:
Weather-Lock Sealing: Silicone gaskets and sealed flange design prevent water, dust, and salt spray from reaching the termination point, extending equipment life in outdoor and marine environments.
Wide Current Range: Covers everything from small control circuits (30A) to large power circuits (800A) with a single adapter type, simplifying inventory and installation.
Dual-Metal Compatible: Accepts both copper and aluminum conductors without requiring bi-metallic lugs, reducing material costs and installation time.
Corrosion Resistance: Nickel plating combined with silicone seals provides superior resistance to salt water, chemicals, and industrial pollutants.
High-Pressure Contact: Spring-loaded or bolted contact design ensures low resistance and minimal heating even under full load conditions.
Easy Identification: Color-coded housing allows electricians to quickly identify the current rating of each terminal point during maintenance.
Universal Mounting: Compatible with most GE and third-party bus bars, disconnect switches, and circuit breakers.
