GE VME162PA-344SE-2G - VMEbus 32-Channel Analog Input Module with 2 Gigabit Ethernet Ports for Series 90-70 Systems

GE VME162PA-344SE-2G – VMEbus 32-Channel Analog Input Module with 2 Gigabit Ethernet Ports for Series 90-70 Systems

In stock

Product Introduction:
The VME162PA-344SE-2G is a high-density analog input module for GE Fanuc Series 90-70 VMEbus control systems. The designation breaks down as follows: VME162 identifies the product family, PA indicates Precision Analog, 344 specifies 32 channels with 4-20mA capability, SE indicates Single-Ended inputs, and 2G denotes 2 Gigabit Ethernet ports. This module is unique in that it combines high-precision analog measurement with high-speed Ethernet networking on a single VME card. It is designed for applications that require both accurate process measurement and fast data communication to a plant historian or SCADA system.

Technical Specifications:
Module Type: VMEbus 32-Channel Analog Input
Input Channels: 32 single-ended channels (configurable as 16 differential)
Input Types: 4-20mA, 0-10V, +/- 10V, RTD (Pt100, Pt1000), Thermocouple (J, K, T, E, N, R, S, B)
Resolution: 16-bit A/D conversion
Accuracy: +/- 0.05% of full scale
Sampling Rate: Up to 1000 samples per second (aggregate)
Ethernet Ports: 2 Gigabit Ethernet (10/100/1000Base-T)
Network Protocols: TCP/IP, UDP, Modbus TCP, EtherNet/IP, PROFINET
Isolation: 500V RMS channel-to-ground isolation
VMEbus: VME64x compliant
LED Indicators: Per-channel status LEDs
Form Factor: 3U VME Eurocard

Functional Features:
Dual Gigabit Ethernet: Two Ethernet ports allow simultaneous connection to a control network and a historian network.
High-Speed Sampling: 1000 samples per second enables fast trending of rapidly changing process variables.
Multi-Sensor Support: Accepts thermocouples, RTDs, millivolts, and current/voltage signals on the same module.
On-Board Cold Junction Compensation: Built-in CJC for thermocouple inputs eliminates the need for external CJC modules.
Per-Channel Configuration: Each channel can be independently configured for input type, range, and filtering.
Burnout Detection: Automatically detects open thermocouple or RTD wires and alarms immediately.
Network Redundancy: Supports RSTP, PRP, and HSR for zero-downtime network redundancy.

Application Scenarios:
Process Variable Monitoring: Reads temperature, pressure, flow, and level from dozens of field transmitters simultaneously.
High-Speed Trending: Captures fast-changing signals like vibration or combustion pressure for analysis.
Redundant Plant Networks: The dual Ethernet ports support parallel redundant networks for critical measurements.
Power Plant Instrumentation: Monitors main steam, reheat steam, and feedwater temperatures with high accuracy.
