GE Fanuc VM600 MPC4 - VersaMax Micro PLC with 4 I/O Slots (MPC4 Configuration)

GE Fanuc VM600 MPC4 – VersaMax Micro PLC with 4 I/O Slots (MPC4 Configuration)

In stock

Product Introduction:
The VM600 MPC4 is a compact, cost-effective Programmable Logic Controller (PLC) from GE Fanuc’s VersaMax Micro family. The “VM600” identifies the VersaMax Micro platform, and “MPC4” specifies the configuration with 4 I/O slots (Micro PLC with 4 slots). This controller is designed for small to medium-sized machine control and process applications where a full-sized rack-mount PLC would be overkill. It offers a small footprint, built-in I/O, Ethernet connectivity, and support for up to 4 additional I/O modules. The MPC4 is the workhorse of the VersaMax Micro line, balancing performance, size, and price.

Technical Specifications:
Platform: GE Fanuc VersaMax Micro (VM600)
Configuration: MPC4 (4 I/O slots + CPU)
CPU: 80 MHz processor with 256KB to 1MB program memory
Built-In I/O: 10 to 24 points (digital and/or analog, depending on model)
Expansion Slots: 4 additional I/O slots (mix of digital, analog, specialty)
Ethernet: 10/100Base-T RJ-45 port
Serial: 1 RS-232/RS-485 port (built-in)
Power Supply: 24V DC (integrated)
Programming Software: VersaPro (or Proficy Machine Edition)
Scan Time: 1 to 10 milliseconds depending on program size
I/O Capacity: Up to 128 points total (built-in + expansion)
Mounting: DIN rail or panel mount
Dimensions: Approximately 100mm x 90mm x 60mm (very compact)

Functional Features:
Ultra-Compact Size: Fits in the palm of your hand, ideal for space-constrained panels.
Built-In Ethernet: Native Ethernet for HMI, SCADA, and peer-to-peer communication.
Mixed I/O Support: Accepts digital, analog, thermocouple, RTD, and high-speed counter modules.
Motion Control: Supports up to 4 axis of pulse-and-direction or step/direction servo control.
Web Server: Built-in web page for diagnostics and parameter changes.
Data Logging: Built-in data logging to CSV files on a USB drive or SD card.
Free Programming Software: VersaPro Lite is available at no cost for programming this controller.

Application Scenarios:
Packaging Machines: Controls conveyors, fillers, sealers, and labelers in food and beverage packaging.
Material Handling: Manages sortation systems, lifts, and gates in warehouses.
Small Process Skids: Controls pumps, valves, and heaters in skid-mounted process packages.
OEM Equipment: Used by machine builders as the standard controller for their products.
Building Automation: Controls HVAC, lighting, and access control in small commercial buildings.
