GE VMIVME4140 - VMEbus 4-Channel High-Precision Analog Output Module

GE VMIVME4140 – VMEbus 4-Channel High-Precision Analog Output Module

In stock

Product Introduction:
The GE VMIVME4140 is a 4-channel, high-precision analog output module for VMEbus systems. The “4140” designation indicates 4 channels with the highest accuracy available in the GE VME analog output family. While it has fewer channels than the 16-channel 2540 or 4116, the 4140 offers superior accuracy, lower drift, and faster settling time, making it the board of choice for applications where every millivolt counts. It is commonly used in calibration laboratories, precision manufacturing, and scientific instrumentation where standard 16-channel boards are not accurate enough.

Technical Specifications:
Board Type: VMEbus High-Precision Analog Output Module
Channels: 4 independent analog output channels
Output Types: 4-20mA or 0-10V (per channel configurable)
Resolution: 16-bit D/A conversion
Accuracy: +/- 0.01% of full scale (ten times better than standard 2540)
Linearity: +/- 0.005% of full scale
Drift: Less than 2 ppm per degree Celsius
Settling Time: Less than 5 microseconds
Isolation: 1000V RMS channel-to-channel
Update Rate: 5ms simultaneous update (faster than 16-channel boards)
VMEbus Interface: D32/A32
Power Consumption: Approximately 3 Watts
Form Factor: 3U VMEbus Eurocard

Functional Features:
Ultra-High Accuracy: The 0.01% accuracy makes this board suitable for calibration and metrology applications.
Ultra-Low Drift: The 2 ppm per degree Celsius drift ensures accuracy is maintained across temperature changes.
Fast Settling: The 5 microsecond settling time allows the output to reach its final value almost instantly.
Low Noise: The output noise is less than 10 microvolts RMS, ensuring clean signals.
Per-Channel Trimming: Each channel has a digital trimmer for fine-tuning output accuracy in the field.
Watchdog Timer: Forces outputs to a safe state on communication failure.

Application Scenarios:
Calibration Laboratories: Provides precise reference voltages and currents for calibrating field instruments.
Precision Manufacturing: Controls laser power supplies, semiconductor etching equipment, and optical alignment systems.
Scientific Research: Drives precision magnets, spectrometers, and particle accelerator components.
Medical Device Manufacturing: Controls precise fluid dispensing and temperature control in medical device production.
Aerospace Testing: Provides accurate stimulus signals for testing avionics and flight control systems.
