Honeywell Triconex 3011 - 16-Channel Digital Input Module

Honeywell Triconex 3011 – 16-Channel Digital Input Module

In stock

Product Introduction:
The Triconex 3011 is a 16-channel digital input module that reads discrete (on/off) signals from field devices. The “3011” designation identifies it as a standard 16-channel digital input in the Series 1 family. This is one of the most commonly used modules in any Triconex rack, providing the interface between the safety controller and the physical world of pushbuttons, limit switches, proximity sensors, pressure switches, and solenoid valve feedback. Each of the 16 channels is opto-isolated, providing 500V RMS isolation from the backplane to protect the CPU from voltage spikes and ground loops. The module is safety-rated and defaults all inputs to a known safe state upon power loss.

Technical Specifications:
Module Type: 16-Channel Digital Input Module
Series: Series 1
Channels: 16 independent digital inputs
Input Voltage: 24V DC, 48V DC, 120V AC, 240V AC (software selectable per channel)
Input Type: Dry contact (voltage-free) or wet contact (voltage-powered)
Isolation: 500V RMS opto-isolated per channel
Scan Rate: 10ms to 50ms (configurable)
Debounce Time: 1ms to 100ms adjustable per channel
Diagnostics: Per-channel LED status, short circuit detection, open circuit detection
Power: 5V DC from backplane
Form Factor: 3U Triconex Eurocard
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
16 Independent Channels: Reads 16 discrete signals on a single module, saving rack space.
Voltage Flexibility: Accepts 24V DC, 48V DC, 120V AC, or 240V AC on any channel without hardware changes.
Per-Channel Debouncing: Adjustable debounce filter on each channel eliminates false triggers from noisy mechanical switches.
LED Indicators: Bright LEDs on every channel show real-time input status for instant troubleshooting.
Fail-Safe Design: Inputs default to a known safe state (normally open or normally closed) on power loss.
Hot Swappable: Can be removed and replaced in a redundant system without shutting down the safety function.

Application Scenarios:
Pushbutton Monitoring: Reads operator pushbuttons for manual initiation of safety functions.
Limit Switch Monitoring: Monitors valve travel limit switches and equipment position sensors.
Pressure Switch Monitoring: Reads high-pressure and low-pressure switch contacts for process protection.
Solenoid Feedback: Monitors open/closed status of solenoid valves and motor-operated valves.
Guard Interlock Monitoring: Reads safety guard switches on rotating equipment and access doors.
