Honeywell Triconex 3061E - 16-Channel High-Speed Digital Input Module with Interrupt

Honeywell Triconex 3061E – 16-Channel High-Speed Digital Input Module with Interrupt

In stock

Product Introduction:
The Triconex 3061E is a 16-channel digital input module designed for high-speed discrete signal acquisition. The “3061” identifies it as a digital input module, while the “E” suffix denotes the Enhanced variant, which offers faster scan times and hardware interrupt capability compared to the standard 3061. This module reads 16 discrete (on/off) signals from field devices such as pushbuttons, limit switches, proximity sensors, pressure switches, and solenoid valve feedback contacts. The “E” enhancement adds hardware interrupt capability, meaning the module can immediately notify the CPU when a critical input changes state, rather than waiting for the next scan cycle. This is essential for applications where microsecond response times are required.

Technical Specifications:
Module Type: 16-Channel High-Speed Digital Input Module
Series: Series 1 Enhanced (E)
Channels: 16 independent digital inputs (dry contact or 24V DC)
Input Voltage: 24V DC, 48V DC, 120V AC, 240V AC (software selectable per channel)
Scan Rate: 1ms to 10ms (configurable, faster than standard 3061)
Interrupt Capability: Hardware interrupt on any input change (less than 100 microsecond latency)
Isolation: 500V RMS opto-isolated per channel
Debounce Time: Adjustable from 1ms to 100ms per channel
Diagnostics: Per-channel LED status, short circuit detection, open circuit detection
Power: 5V DC from backplane
Form Factor: 3U Triconex Eurocard
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
Hardware Interrupts: The CPU is interrupted immediately when any input changes state, ensuring zero-latency response for critical signals.
Per-Channel Debouncing: Each input has an adjustable debounce filter to eliminate false triggers from noisy mechanical switches.
High-Speed Scanning: Scans all 16 inputs in as little as 1ms, capturing fast events that standard modules would miss.
Voltage Flexibility: Accepts 24V DC, 48V DC, 120V AC, or 240V AC on any channel without hardware changes.
LED Indicators: Bright LEDs on every channel show real-time input status for instant troubleshooting.
Fail-Safe Design: Inputs default to a known safe state (normally open or normally closed) upon loss of backplane power.

Application Scenarios:
Emergency Stop Buttons: Reads E-stop buttons with interrupt capability, ensuring the CPU reacts in under 100 microseconds.
Valve Position Feedback: Monitors open/closed status of solenoid valves and motor-operated valves.
Guard Switches: Reads safety guard interlocks on rotating equipment with high-speed scanning.
Flame Detector Status: Monitors flame detector relay contacts for fire protection systems.
High-Speed Counting: Counts products on a conveyor or events in a test system at speeds exceeding 10,000 per minute.
