GE IC200BEM002 PROFIBUS‑DP Slave Communication Module

Technical Specifications

• Manufacturer: GE Fanuc / Emerson Automation
• Model: IC200BEM002
• Series: GE VersaMax PLC System
• Function: PROFIBUS‑DP Network Slave Module
• Supported Protocol: PROFIBUS‑DP (RS‑485)
• Baud Rate: 9.6 kbps to 12 Mbps (auto‑detected)
• Network Address: 1 to 125 (software‑configurable)
• Data Exchange: Up to 244 bytes input / 244 bytes output
• Max Nodes: 32 stations (without repeater); 125 stations (with repeater)
• Power Supply: 5 V DC from PLC backplane
• Current Consumption: 460 mA @ 5 V DC
• Dimensions (W×H×D): 54.8 × 96.5 × 102 mm
• Weight: Approximately 0.32 kg
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 5% to 95% (non‑condensing)
• Connector: 9‑pin D‑sub (PROFIBUS interface)
• LED Indicators: OK (module health), COM (communication status)
• Firmware: Flash‑upgradable (version 1.00 or later)

Key Features

1. PROFIBUS‑DP Slave Operation
   • Operates as a PROFIBUS‑DP slave, controlled by a PROFIBUS master for deterministic data exchange.
   • Supports standard PROFIBUS‑DP frames for interoperability with third‑party masters and slaves.
2. High‑Speed & Flexible Communication
   • Auto‑detects baud rates from 9.6 kbps to 12 Mbps to match network requirements.
   • Provides up to 244 bytes of input and 244 bytes of output data for extensive I/O mapping.
3. Robust Network Scalability
   • Connects up to 32 nodes per segment without repeaters, or 125 nodes with repeaters.
   • Allows multiple IC200BEM002 modules in one VersaMax PLC for multi‑segment networks.
4. Compact & Industrial‑Grade Design
   • Features a space‑saving form factor for DIN‑rail mounting in standard VersaMax racks.
   • Withstands wide temperature ranges and humidity for reliable operation in harsh industrial environments.
5. Diagnostic LEDs & Easy Maintenance
   • Equipped with OK and COM LEDs for real‑time status monitoring and quick fault identification.
   • Supports GE programming software for configuration, network setup, and firmware updates.
6. Seamless VersaMax PLC Integration
   • Plugs directly into any VersaMax PLC I/O slot, using the backplane for power and data exchange.
   • Maps PROFIBUS data to the PLC’s internal memory for transparent access by the user program.

Application Scenarios

• Factory Automation & Discrete Manufacturing
  • Automotive Assembly Lines: Connects VersaMax PLC to robotic controllers, conveyors, and remote I/O for synchronized production.
  • Packaging Machinery: Links to variable frequency drives (VFDs), sensors, and actuators for precise motion control.
• Process Control Industries
  • Chemical & Petrochemical Plants: Interfaces with flow meters, pressure transmitters, and control valves for distributed process monitoring.
  • Water & Wastewater Treatment: Connects to level sensors, pumps, and dosing units across treatment facilities.
• Building Automation & Infrastructure
  • HVAC Systems: Integrates with temperature controllers, dampers, and fans for energy‑efficient climate control.
  • Smart Buildings: Manages lighting, security, and access control systems via PROFIBUS networks.
• Industrial Machinery & Heavy Equipment
  • Machine Tools: Connects CNC machines, servo drives, and cooling systems for coordinated motion control.
  • Material Handling: Controls cranes, hoists, and conveyor systems in warehouses and logistics hubs。
