RS-FS-9001 362A1052P404 - Remote Station Fiber Switch Module

RS-FS-9001 362A1052P404 – Remote Station Fiber Switch Module

In stock

Product Introduction:
The GE RS-FS-9001 362A1052P404 is a specific configuration variant of the RS-FS-9001 Remote Station Fiber Switch. The long suffix “362A1052P404” is a configuration code that defines the exact hardware and firmware setup for this particular unit. This code specifies the SFP module types (single-mode vs. multimode, wavelength), the pre-loaded firmware version, the default IP address, and any customer-specific customizations. While the base board is identical to the RS-FS-9001, this configuration code ensures that the board arrives from the factory pre-configured for a specific installation, eliminating the need for on-site programming.

Technical Specifications:
Board Type: Remote Station Fiber Switch (RS-FS-9001)
Configuration Code: 362A1052P404
Fiber Ports: 4 SFP slots configured for single-mode fiber, 1310nm wavelength (based on configuration code)
Ethernet Ports: 8 RJ-45 Gigabit Ethernet ports
Pre-Configured IP Address: Specific to the configuration code (e.g., 192.168.1.100)
Firmware Version: Locked to a specific revision matching the configuration code
Redundancy: MRP enabled with pre-assigned ring ID
VLAN Configuration: Pre-configured VLANs for control, historian, and HMI traffic
Power Input: 125V DC (pre-configured for the specific rack power supply)

Functional Features:
Plug-and-Play Deployment: Arrives from the factory fully configured; simply insert into the rack and connect fiber cables.
Reduced Commissioning Time: Eliminates hours of on-site configuration, reducing plant downtime during installation.
Configuration Locking: The configuration code is locked to prevent accidental changes that could disrupt the network.
Traceability: The 362A1052P404 code provides full traceability to the manufacturing batch, test results, and shipment records.
Warranty Validation: GE validates the warranty only for boards with the correct configuration code installed in the correct rack position.
