Triconex 4000153-010 - 16-Channel Digital Output Module for Tricon Safety Controller

Triconex 4000153-010 – 16-Channel Digital Output Module for Tricon Safety Controller

In stock

Product Introduction:
The Triconex 4000153-010 is a 16-channel digital output module for the Tricon safety instrumented system. This board provides 16 channels of discrete (on/off) output control via electromechanical relays. Each relay can switch up to 5 Amps at 250V AC or 30V DC, making this module suitable for driving high-power loads such as solenoid valves, contactor coils, indicator lamps, and alarm horns directly from the safety controller. The “010” configuration indicates the base memory configuration. Like all Tricon I/O, this module is triple modular redundant: three independent processors control every output, and the relays are energized only when at least two out of three processors agree on the output state. This ensures that a stuck relay or a failed processor cannot cause a dangerous output.

Technical Specifications:
Board Type: Digital Output Module (Relay)
Configuration: 010 (base memory)
Channels: 16 independent relay output channels
Contact Rating: 5 Amps at 250V AC or 30V DC (Form C, changeover)
Coil Voltage: 24V DC
Response Time: 20ms maximum (relay actuation time)
Isolation: 250V RMS channel-to-channel and channel-to-ground
Redundancy: Full TMR with automatic voting
Power Consumption: Approximately 6 Watts (including relay coil power)
Form Factor: Tricon I/O Carrier compatible module
Diagnostics: Per-channel LED, relay coil current monitoring, contact weld detection

Functional Features:
Electromechanical Relays: Provides true dry-contact outputs that are compatible with any field device, regardless of voltage or current.
Contact Weld Detection: Monitors the relay coil current; if a relay contact welds shut, the coil current changes and the module alarms immediately.
Per-Channel Independence: Each of the 16 channels can be independently configured for normally energized or normally de-energized operation.
Fail-Safe Configuration: Outputs can be configured to de-energize (safe state) on communication loss, processor failure, or power loss.
LED Indicators: Bright LEDs on every channel show real-time output status for quick troubleshooting.
Hot Swappable: Can be replaced while the system is running in redundant configuration.
