Product Introduction:
The Triconex 7400166-390 is a critical processor module for the Triconex TriStation Safety Instrumented System (SIS). This module serves as one of the three redundant processors in a Triconex safety controller chassis. It executes the safety logic, monitors all I/O points, and performs the voting logic that ensures the system operates safely even if one processor fails. The “7400166-390” is the specific part number for this processor revision, which is compatible with the Triconex 3008 and 3009 controller chassis. This board is the “brain” of the entire safety system, running the application program that protects people, equipment, and the environment from hazardous events.

Technical Specifications:
Board Type: Safety Controller Processor Module
System: Triconex TriStation (Series 3008/3009)
Architecture: Triple Modular Redundancy (TMR) with three identical processors
Processor: 32-bit RISC processor running at high speed
Memory: 32MB RAM for application storage and execution
Communication: Dual redundant communication paths (TMRnet) between all three processors
Voting Logic: Hardware-based 2-out-of-3 voting on every scan cycle
Scan Time: As fast as 50 milliseconds for safety logic execution
I/O Capacity: Supports up to 256 I/O points per controller (expandable)
Certifications: SIL 3 (Safety Integrity Level 3) certified, IEC 61508 compliant
Operating Temperature: 0 to 60 degrees Celsius (standard)
Power Consumption: Approximately 15 Watts per processor module
Form Factor: Standard Triconex Eurocard (3U height)

Functional Features:
Triple Modular Redundancy: Three processors run the exact same program simultaneously. The hardware voter compares results every 50 milliseconds. If one processor disagrees, it is automatically taken out of service while the other two continue operating.
Hardware Voting: The voting is performed in hardware, not software, ensuring that even if all three processors fail in the same way, the hardware voter still provides a safe output.
Dual Communication Paths: Every processor has two independent communication paths to every I/O module, ensuring that a single cable failure never causes a loss of safety function.
