Triconex 9556-810F - Triple Redundant 8-Port High-Speed Serial Communication Module with Fiber Optic

Triconex 9556-810F – Triple Redundant 8-Port High-Speed Serial Communication Module with Fiber Optic

In stock

Product Introduction:
The Triconex 9556-810F is a high-speed serial communication module for Triconex Safety Instrumented Systems. The “9556” identifies it as a multi-port serial communication module, “810” specifies 8 ports with 10 ports of additional capability (or 8 ports at high speed), and the “F” suffix indicates fiber optic connectivity. This board provides 8 independent RS-232/RS-485 serial ports, each capable of communicating with field devices, remote I/O racks, modems, GPS receivers, or other controllers at baud rates up to 115.2 kbps. The fiber optic “F” variant provides galvanic isolation and long-distance communication capability (up to 2 kilometers per fiber link). The TMR architecture ensures SIL 3 safety certification for all communication channels.

Technical Specifications:
Board Type: Triple Redundant High-Speed Serial Communication Module
Model: 9556-810F
Ports: 8 RS-232/RS-485 serial ports (fiber optic isolated)
Baud Rate: 300 to 115,200 bps (configurable per port)
Fiber Distance: Up to 2 kilometers per fiber link (multimode)
Protocols: Modbus RTU/ASCII, Triconex proprietary, DNP3, Profibus DP (slave)
Isolation: 1500V RMS fiber optic isolation on all ports
Redundancy: Full TMR with 2-out-of-3 voting
LED Indicators: Per-port TX/RX LEDs for instant status verification
Operating Temperature: 0 to 60 degrees Celsius
Form Factor: Triconex standard module
Power Consumption: Approximately 6 Watts
Certifications: SIL 3, IEC 61508, ATEX

Functional Features:
Fiber Optic Isolation: Provides complete galvanic isolation between the Triconex backplane and field devices, eliminating ground loops and protecting against voltage transients.
8 Independent Ports: Each port operates independently, allowing simultaneous communication with 8 different devices or networks.
Long-Distance Communication: Fiber optic links extend communication range to 2 kilometers, far beyond the 15-meter limit of RS-232.
Protocol Flexibility: Each port can be configured for a different protocol, enabling integration with diverse field devices.
Per-Port Diagnostics: Monitors each port for errors, timeouts, and framing errors, reporting faults to the CPU.
Hot Swappable: Can be replaced while the system is running.
