Foxboro FBM216 - I/A Series Ethernet TCP/IP Communication Module

Foxboro FBM216 – I/A Series Ethernet TCP/IP Communication Module

In stock

Product Introduction:
The Foxboro FBM216 is an Ethernet communication module for the I/A Series Distributed Control System. This module provides standard Ethernet TCP/IP connectivity between the I/A Series controller and external systems such as historians, asset management platforms, engineering workstations, and corporate networks. The FBM216 supports both Modbus TCP and native Foxboro I/A Series Ethernet protocols, allowing seamless data exchange with third-party systems. It is the primary module for plant-wide data collection, remote monitoring, and system integration. Unlike the fieldbus modules (FBM207, FBM214, FBM215) that connect to field devices, the FBM216 connects to plant-level and enterprise-level systems.

Technical Specifications:
Board Type: Ethernet TCP/IP Communication Module
Protocol: TCP/IP, Modbus TCP, UDP, HTTP, SNMP, Foxboro native Ethernet
Speed: 10/100Base-T auto-negotiation
Connection: Standard RJ-45 Ethernet port
IP Address: Configurable static or DHCP
Data Rate: Up to 100 Mbps
Isolation: 1500V RMS galvanic isolation
Processor: 32-bit RISC with dedicated Ethernet controller
Memory: 16MB Flash, 8MB RAM
Power: 5V DC from I/A Series backplane
Form Factor: 3U I/A Series Eurocard
Operating Temperature: 0 to 60 degrees Celsius

Functional Features:
Plant-Wide Connectivity: Provides Ethernet connectivity for historian data collection, remote monitoring, and asset management integration.
Modbus TCP Support: Communicates with any Modbus TCP device (PLCs, RTUs, smart sensors) on the plant network.
SNMP Support: Supports SNMP v1/v2c/v3 for network management and alarm reporting to NMS platforms.
Web Server: Built-in web server allows remote access to module diagnostics and configuration via a standard browser.
Dual Ethernet Ports: Some revisions include a second Ethernet port for redundant network connectivity.
Firewall Compatible: Supports IP filtering and port blocking for secure integration with corporate networks.
Hot Swappable: Can be replaced while the system is running.
