GE Fanuc / Emerson IC695SPF002

In stock

Product Overview

The IC695SPF002 is a compact, high‑performance communication module designed for the GE Fanuc PACSystems RX3i programmable automation controller (PAC) platform. It functions as a PROFINET IO scanner that connects remote RX3i I/O racks (including Series 90‑30 and RX3i modules) to a PROFINET IO controller, enabling high‑speed, deterministic industrial Ethernet communication. The module supports both copper (RJ‑45) and fiber (SFP) connectivity, making it suitable for long‑distance and harsh‑environment applications.

Technical Specifications

Manufacturer: GE Fanuc (now Emerson Electric)
Part Number: IC695SPF002
Module Type: SFP Scanner Module (PROFINET IO)
Compatible Platform: PACSystems RX3i Series
Ports:
- 4 × Ethernet Ports:
  - 2 × RJ‑45 (Copper) – 10/100 Mbps
  - 2 × SFP Slots – for fiber transceivers
Network Standard: 100Base‑FX (Fiber), 10/100 Mbps (Copper)
Fiber Type: Multi‑Mode Fiber (MMF)
Max Fiber Distance: 2 km (MMF at 100 Mbps)
Supported Protocols: PROFINET IO (Version 2.2), Modbus TCP/IP
Data Refresh Rate: Configurable (PROFINET)
Power Supply: 3.3 VDC to 5 VDC; 0.5 A (no SFP), 1.2 A (2 SFPs)
Operating Temperature: 0°C to +60°C
LED Indicators: For power, link, activity, and fault status
SD Card Support: Yes (for configuration/logging)
Dimensions (W × H × D): Compact SFP form factor
Weight: 0.06 kg (0.13 lbs)

Key Features

High‑Speed Industrial Communication
- Supports 10/100 Mbps (copper) and 100 Mbps (fiber) for real‑time data exchange.
- Implements PROFINET IO for deterministic, high‑performance I/O control.
Flexible Connectivity
- Dual RJ‑45 ports for direct copper Ethernet connections.
- Dual SFP slots for fiber optic links, extending communication distance up to 2 km (MMF).
- Supports daisy‑chain, star, and ring network topologies.
Industrial‑Grade Reliability
- Operates reliably in 0°C to +60°C temperatures.
- Supports Media Redundancy Protocol (MRP) for ring networks, ensuring seamless failover and high system uptime.
- Compact, rugged design for harsh industrial environments.
Seamless Integration
- Designed for PACSystems RX3i controllers (requires CPU315/CPU320, firmware v7.0+).
- Scans data on the local rack and exchanges I/O data with PROFINET controllers.
- Compatible with GE Series 90‑30 and RX3i I/O modules.
Easy Configuration & Maintenance
- Configurable via GE’s Proficy Machine Edition software.
- LED indicators provide real‑time status monitoring.
- SD card slot for easy backup/restore of configurations.
