GE Fanuc IS200BPPBH2BMD Processor Board (Mark VIe CPU)

In stock

Product Overview:
The GE Fanuc IS200BPPBH2BMD is the central processor board (CPU) for the Mark VIe turbine control system. This is the “brain” of the entire control system, executing the turbine control algorithms, managing all I/O communication, handling network traffic, and running the HMI (Human Machine Interface). It is a high-performance dual-core processor module designed for gas turbine, steam turbine, and generator control applications in power generation, oil and gas, and industrial processing. The “BMD” suffix indicates a specific firmware revision and hardware configuration optimized for ** single-redundant or dual-redundant processor architectures**.

Technical Specifications:
Series: GE Mark VIe Control System
Processor: Dual-Core Intel Atom or Freescale QorIQ P2020 (depending on revision)
Clock Speed: 1.0 GHz to 1.6 GHz
RAM: 2 GB DDR3 ECC SDRAM
Flash Storage: 4 GB CompactFlash (for OS and Application)
Redundancy: Supports Single or Dual Redundant Processor Configuration
Backplane Bus: GEnet (Mark VIe Backplane)
Ethernet: 2 x Gigabit Ethernet (via IS200AEPCH1BAA or integrated)
Serial Ports: 2 x RS-232/RS-485 (via IS200CMX module or integrated)
Operating Temperature: 0°C to +60°C
Power Consumption: < 15 Watts
MTBF: > 200,000 Hours

Functional Features:
Dual-Core Processing: One core dedicated to real-time control execution (deterministic), the other to communications and HMI (non-deterministic)
Redundant Architecture: In dual-redundant configuration, two BPPBH2BMD boards run in lockstep; if one fails, the other takes over with zero bump-less transfer
Integrated Web Server: Full HMI accessible via any web browser on the plant network
Application Execution: Runs Mark VIe turbine control applications (gas turbine, steam turbine, generator, excitation)
Historical Data Logging: Built-in data historian for trending and event recording
Security: Supports user authentication, role-based access control, and audit logging

Performance Parameters:
Control Cycle Time: 10 ms to 100 ms (Configurable per application)
I/O Scan Time: < 5 ms for full rack
Network Throughput: Up to 100 Mbps
Boot Time: < 30 Seconds (Cold Boot)
Failover Time (Redundant): 0 ms (Bumpless)

Material Composition:
PCB: 10-Layer FR-4 High-Tg with dedicated power and ground planes
Processor: Industrial-Grade Freescale QorIQ P2020 or Intel Atom E3800 Series
Memory: Samsung or Micron DDR3 ECC SODIMM
Flash: Industrial CompactFlash (SanDisk or Transcend)
Connectors: High-Density GEnet Backplane Connector + Ethernet RJ45
