GE IC200PBI001 – VersaMax PROFIBUS-DP Network Interface Unit (NIU)

In stock

Product Introduction: The IC200PBI001, designed by GE Fanuc (Emerson Automation), is a high-performance PROFIBUS-DP slave network interface unit within the VersaMax I/O system. It acts as a communication bridge, connecting VersaMax I/O modules to a PROFIBUS-DP industrial fieldbus network, enabling data exchange between local I/O and a PROFIBUS-DP master (e.g., PLC, HMI, or SCADA system). It supports high-speed, reliable communication for distributed control systems in harsh industrial environments.

Technical Specifications

Manufacturer: GE Fanuc (Emerson Automation)
Model: IC200PBI001
Series: VersaMax PLC & I/O System
Module Type: PROFIBUS-DP Slave Network Interface Unit (NIU)
Protocol: PROFIBUS-DP V1.0 (Class 1 Slave)
Network Address: 1–125 (configurable via DIP switches)
Baud Rate: 9.6 kbps to 12 Mbps (auto-detected or manually configured)
Max I/O Data: 375 bytes total (up to 244 bytes input or 244 bytes output)
Max I/O Modules: 8 modules per NIU; controls up to 64 I/O points
Diagnostic Data: 5 bytes standard PROFIBUS diagnostics; 2 bytes status/control
Connector: 9-pin D-sub (RS-485 electrical standard)
Isolation: 500 V DC between communication interface and logic ground
Backplane Power: 5 VDC @ 250 mA; 3.3 VDC @ 10 mA
External Power: 24 VDC (optional, for field-side components)
Dimensions (W×H×D): 120 mm × 50 mm × 90 mm
Weight: 0.14 kg (0.31 lbs)
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +70°C
Relative Humidity: 5%–95% (non-condensing)
Certifications: CE, UL, CSA
Mounting: DIN rail or VersaMax I/O carrier

Key Features

PROFIBUS-DP Slave Operation: Seamlessly integrates VersaMax I/O into PROFIBUS-DP networks as a slave node.
Auto Baud Rate Detection: Automatically detects and adapts to network speeds from 9.6 kbps to 12 Mbps.
High I/O Capacity: Handles up to 375 bytes of process data, supporting large-scale I/O control.
LED Diagnostic Indicators:
- PWR: Lights when backplane power is active.
- OK: Indicates module health and operational status.
- FLT: Alerts to internal faults or I/O module issues.
- NET: Shows network communication status (green=active, amber=error).
DIP Switch Configuration: Simplifies address setting without software.
Electrical Isolation: Protects the PLC backplane from fieldbus electrical noise and voltage spikes.
Compact & Robust Design: Standard VersaMax form factor for easy integration; built for harsh industrial conditions.
Hot-Swappable: Enables replacement without system shutdown.
