GE IC200PWB101D – VersaMax Power Supply Booster Carrier Module

In stock

Product Introduction: The IC200PWB101D, manufactured by General Electric (GE), is a critical booster carrier module in the VersaMax PLC series. It serves as a dedicated mounting and power distribution base for additional VersaMax power supply modules, extending backplane power capacity for large-scale I/O configurations. By enabling supplementary power integration, it ensures stable, redundant power delivery to CPUs, network interface units (NIUs), and diverse I/O modules, making it essential for high-demand industrial automation systems.

Technical Specifications

Manufacturer: General Electric (GE Fanuc / Emerson Automation)
Model: IC200PWB101D
Series: VersaMax PLC System
Module Type: Power Supply Booster Carrier
Compatible Power Supplies: IC200PWR001, IC200PWR002, IC200PWR101, IC200PWR102
Backplane Compatibility: All VersaMax I/O carriers and CPU/NIU modules
Input Voltage (Auxiliary): 24VDC ±10% (for carrier logic)
Power Dissipation: 2.5W maximum
Isolation Rating: 1500VAC (1 minute) channel-to-logic
Enclosure Rating: IP20 (protects against solid objects >12mm)
Mounting: 35mm DIN rail or VersaMax I/O carrier
Dimensions (W×H×D): 110mm × 66.8mm × 50mm
Weight: 0.25kg (0.55lbs)
Operating Temperature: -20°C to +70°C (-4°F to 158°F)
Storage Temperature: -40°C to +85°C (-40°F to 185°F)
Relative Humidity: 5%–95% (non-condensing)
Certifications: CE, UL, CSA (industrial safety and EMC compliance)
Terminal Type: Spring-clamp (10 terminals), torque: 1.1–1.4Nm
Reliability (MTBF): 50,000 hours (industrial-grade durability)

Key Features

Power Capacity Extension: Distributes supplementary power to all I/O modules to its right (until the next booster carrier), eliminating backplane power overload in large systems.
Seamless Module Integration: Snaps securely onto VersaMax DIN rails or existing carriers; hot-swappable for tool-free replacement without system shutdown.
Robust Electrical Isolation: 1500VAC isolation shields the main backplane from field-side noise, voltage spikes, and ground loops, enhancing system stability.
Universal Compatibility: Works with all VersaMax power supplies (AC/DC input) and I/O modules (analog/digital, input/output), enabling flexible system design.
Industrial-Grade Durability: Wide temperature tolerance (-20°C to +70°C) and IP20 rating ensure reliable operation in harsh factory, process, and outdoor environments.
Simplified Wiring & Maintenance: Spring-clamp terminals enable fast, secure connections; diagnostic LEDs (PWR OK) provide real-time status for quick troubleshooting.
Redundancy Support: Facilitates redundant power supply configurations (primary + backup) for mission-critical applications requiring zero downtime.
