Technical Specifications
- Manufacturer: General Electric (GE Fanuc / Emerson Automation)
- Model: IC200PWR002
- Series: VersaMax PLC System
- Module Type: Backplane Power Supply (Expanded 3.3V)
- Input Voltage: 18–30VDC (24VDC nominal)
- Input Power: 11W
- Holdup Time: 10ms
- Inrush Current: 20A @ 24VDC; 25A @ 30VDC (≤6ms duration)
- Output Voltages: 3.3VDC, 5VDC
- Output Current Ratings:
- Total Combined: 1.5A maximum
- 3.3VDC Output: 1.0A maximum
- 5VDC Output: (1.5A − I₃.₃V) maximum
- Protection Features: Short circuit, overload, reverse polarity
- Isolation: Non-isolated (DC− internally grounded to frame)
- Dimensions (W×H×D): 110mm × 66.8mm × 50mm
- Weight: 0.18kg (0.40lbs)
- Operating Temperature: 0°C to +60°C (32°F to 140°F)
- Storage Temperature: −40°C to +85°C (−40°F to 185°F)
- Relative Humidity: 5%–95% (non-condensing)
- Certifications: CE, UL, CSA, Class I Div 2 Groups ABCD
- Protection Class: IP20
- Mounting: DIN rail or VersaMax I/O carrier
Key Features
- Dual-Rail Output: Provides stable 3.3VDC (up to 1.0A) and 5VDC (up to 1.5A) for VersaMax backplane components.
- Flexible Operation: Acts as primary power when connected to CPU/NIU or supplementary power on a booster carrier.
- High Efficiency: Utilizes advanced switching technology for low power consumption and minimal heat generation.
- Comprehensive Protection: Integrates short-circuit, overload, and reverse-polarity protection to safeguard modules from electrical damage.
- LED Status Indicators: Equipped with power and fault LEDs for real-time monitoring of operational status.
- Compact & Robust Design: Standard VersaMax form factor enables easy integration into control cabinets; built to withstand harsh industrial conditions.
- Wide Environmental Tolerance: Operates reliably across extended temperature and humidity ranges.
