GE IC200PWR102D – VersaMax Expanded AC Power Supply Module

In stock

Product Introduction: The IC200PWR102D, manufactured by General Electric (GE Fanuc, now Emerson Automation), is a high-efficiency expanded power supply in the VersaMax PLC series. Designed to deliver stable 3.3VDC and 5VDC power to the VersaMax backplane, it powers CPUs, I/O modules, and network interface units. It supports a wide AC input range for global use and provides comprehensive protection, ensuring reliable operation in harsh industrial environments. As a key power source or supplementary booster supply, it optimizes power distribution for VersaMax systems.

Technical Specifications

Manufacturer: General Electric (GE Fanuc / Emerson Automation)
Model: IC200PWR102D
Series: VersaMax PLC System
Module Type: Expanded AC-to-DC Power Supply
Input Voltage: 85–132VAC (120V) / 176–264VAC (240V), auto-ranging
Input Frequency: 47–63Hz
Input Power: 27VA maximum
Input Current: ≤1.5A @ 120VAC
Output Voltages: 3.3VDC (logic), 5VDC (logic)
Output Current: 1.0A @ 3.3VDC; 1.5A @ 5VDC (total 1.5A max)
Hold-Up Time: 20ms minimum (maintains output during brief input interruptions)
Efficiency: ≥75% typical
Protection Features: Short-circuit, overload, overvoltage, and overtemperature protection
Dimensions (W×H×D): 124mm × 127mm × 71mm (4.9in × 5.0in × 2.8in)
Weight: 0.4kg (0.88lbs)
Operating Temperature: 0°C to +60°C (32°F to 140°F)
Storage Temperature: -40°C to +70°C (-40°F to 158°F)
Relative Humidity: 5%–95% (non-condensing)
Certifications: CE, UL, CSA (industrial safety and EMC compliance)
Mounting: DIN rail or VersaMax I/O carrier
LED Indicators: OK (power status), FLD PWR (field power present)

Key Features

Wide-Range AC Input: Auto-ranging 85–264VAC input accommodates global power grids without manual adjustments.
Dual Voltage Output: Provides 3.3VDC and 5VDC to power all VersaMax backplane components efficiently.
Robust Protection Mechanisms: Defends against short circuits, overloads, overvoltage, and overheating to prevent module and system damage.
20ms Hold-Up Time: Sustains output power during brief AC input disruptions, ensuring system stability.
Diagnostic LED Indicators: Clear OK and FLD PWR LEDs enable real-time status monitoring and quick troubleshooting.
Compact & Durable Design: Standard DIN rail mount saves cabinet space; rugged construction withstands industrial shock and vibration.
Hot-Swappable: Supports replacement without shutting down the entire VersaMax system, minimizing downtime.
Versatile Deployment: Functions as a primary power supply or supplementary booster supply on power carrier modules for expanded I/O systems.
