GE IC697BEM713 – Series 90-70 Bus Transmitter Module (BTM)

In stock

Product Description:

The IC697BEM713 is a core bus expansion module for the GE Series 90-70 PLC platform. Installed in the main CPU rack, it extends the system I/O capacity by connecting up to 7 additional remote racks, enabling large-scale distributed control. It integrates a high-speed parallel programming port and a daisy-chain expansion port, eliminating the need for hardware jumpers and supporting full software configuration. It uses Belden 9182 cable for reliable bus communication.

Technical Specifications:

Manufacturer: GE Fanuc (Emerson Automation)
Series: Series 90-70 PLC System
Module Type: Bus Transmitter Module (BTM), single-slot
Ports: 1 × parallel programming port (top); 1 × expansion output port (bottom)
Bus Cable: Belden 9182
Expansion Capacity: Up to 7 remote IC697 racks
LED Indicators: 3 green LEDs (MODULE OK, PGMR ACTIVE, BUS ACTIVE)
Configuration: Software-based (no DIP switches/jumpers)
Backplane Compatibility: Series 90-70 backplane (not Slot 1, CPU dedicated)
Power Consumption: 1.2A @ 5VDC
Operating Temperature: 0°C to +60°C
Storage Temperature: -40°C to +85°C
Weight: Approx. 0.43 kg
Certifications: CE, UL, CSA, RoHS

Key Features:

Massive I/O Expansion: Overcomes single-rack limits, supporting thousands of I/O points for large systems.
High-Speed Parallel Communication: Ensures fast, deterministic data transfer between the main CPU and remote racks.
Integrated Programming Port: Allows direct connection of a programmer without additional adapters.
Daisy-Chain Cascading: Simplifies wiring and reduces interference in complex layouts.
Software-Only Configuration: Minimizes setup errors and simplifies maintenance.
Real-Time Diagnostics: LEDs provide instant status feedback for quick troubleshooting.
Industrial Ruggedness: Withstands vibration, shock, and harsh EMI environments.

Applications:

Large-Scale Manufacturing: Automotive assembly plants and electronics factories with distributed I/O across multiple lines.
Process Industries: Petrochemical, metallurgy, and cement plants with distributed control systems (DCS).
Water Infrastructure: Large treatment plants and municipal networks connecting central control to remote pump stations.
Power & Energy: Thermal power plants and substations managing auxiliary systems with remote I/O racks.
