GE IC200PWR102B VersaMax Expanded Power Supply Module

Technical Specifications

• Manufacturer: GE Fanuc / Emerson Automation
• Model: IC200PWR102B
• Series: VersaMax PLC
• Product Type: Expanded AC Power Supply
• Input Voltage (AC):
  • 85–132 VAC (120 VAC nominal, with jumper)
  • 176–264 VAC (240 VAC nominal, without jumper)
• Input Frequency: 47–63 Hz
• Input Power: 27 VA
• Output Voltages: 5 VDC, 3.3 VDC
• Output Current (Max):
  • 5 VDC: 1.5 A
  • 3.3 VDC: 1.0 A
  • Total: 1.5 A
• Efficiency: ≥85%
• Voltage Regulation: ±3%
• Ripple & Noise: ≤100 mV (p-p)
• Holdup Time: 20 ms (typical)
• Isolation: 1500 VAC (input-to-output, 1 minute)
• Operating Temperature: 0°C to +60°C
• Storage Temperature: -25°C to +70°C
• Relative Humidity: 5%–95% (non-condensing)
• Dimensions (W×H×D): 40 × 50 × 133 mm (1.57 × 1.97 × 5.24 in)
• Weight: Approximately 0.3 kg
• Protection: Overload, short-circuit, over-temperature
• LED Indicators: Power OK, Overload

Key Features

1. Universal AC Input Range
   • Accepts 120 VAC or 240 VAC nominal inputs via a selectable jumper, enabling global deployment without hardware modification.
2. Dual Regulated DC Outputs
   • Supplies both 5 VDC and 3.3 VDC to the VersaMax backplane, powering CPUs, digital/analog I/O, and communication modules.
3. High Efficiency & Reliability
   • Delivers ≥85% efficiency to reduce heat generation and energy consumption.
   • Industrial-grade components ensure stable operation in electrically noisy environments.
4. Comprehensive Protection Mechanisms
   • Integrates overload, short-circuit, and over-temperature protection to safeguard the module and connected PLC hardware.
5. Compact & Rack-Mountable Design
   • Plugs directly into any VersaMax PLC rack slot, requiring no additional wiring or adapters.
   • Low-profile, space-saving form factor optimizes cabinet layout.
6. Diagnostic LEDs for Quick Maintenance
   • Features dedicated “Power OK” and “Overload” LEDs for real-time status monitoring and fast fault isolation.

Application Scenarios

• Factory Automation
  • Assembly Lines: Powers VersaMax PLCs controlling conveyors, robotic arms, and assembly stations.
  • Packaging Machinery: Supports high-density I/O systems for labeling, filling, and sealing equipment.
• Process Industries
  • Water/Wastewater Treatment: Provides reliable power to PLCs monitoring pumps, valves, and level sensors.
  • Food & Beverage: Maintains stable power for temperature controllers, mixers, and conveyor systems.
• Building Infrastructure
  • HVAC Systems: Powers VersaMax PLCs regulating heating, ventilation, and air conditioning in commercial buildings.
  • Elevator & Escalator Controls: Supports PLC-based motion control and safety monitoring systems.
• General Industrial Machinery
  • Machine Tools: Supplies power to VersaMax PLCs controlling CNC machines, lathes, and milling equipment.
  • Material Handling: Powers PLCs managing cranes, hoists, and automated guided vehicles (AGVs).
